Inverter Solis Mini 1500 4G

Name: Tubelight 400
SKU: 4018
Availability: InStock

SKU: inverter-solis-mini-3000-4g-1 Kategori: Grid Tied, Inverter Tag: energi surya, Hemat Energi, inverter, On Grid, Pembangkit Listrik Tenaga Surya, toko panel surya surabaya.

● Seri MiNi- Diperluas hingga 3600W
● Teknologi switching frekuensi tinggi-Smallersmarter
● DRM terintegrasi sepenuhnya sesuai dengan AS47772: 2015
● Ringkas dan ringan
● Rentang tegangan input 50V-500V- startup sangat rendah
● Efisiensi Maksimal 97,5%
● Algoritma MPPT yang tepat
● Manajer Daya Ekspor (EPM) Terintegrasi
● Antarmuka RS485 WiFi / GPRS (opsional)
● Pemantauan WiFi tersedia — tersedia aplikasi iphone dan android
● 5 tahun garansi standar 20 tahun upgrade opsional

*)Barang Akan dikirimkan 21-40 hari kerja

Rp10,546,938

Compare

Model	Solis-mini-1500-4G
Energy Source	PV

Input Side(DC)
Max. DC input power(kW)	1.8
Max. DC input voltage(V)	600
Start-up voltage(V)	60
MPPT voltage range(V)	50-500
MPPT number	1
Max input string number / Max. Short Circuit current for each MPPT	11 A / 17.2 A

Output Side (AC)
Rated output power(kW)	1.5
Max. apparent output power(kVA)	1.7
Max. output power(kW)	1.7
Rated grid voltage(V)	220/230
Rated grid frequency(Hz)	50/60
Operation phase	Single
Rated grid output current(A)	6.8/6.5
Max. output current(A)	8.1
Power Factor (at rated output power)	0.8leading … 0.8lagging
THDi (at rated output power)	<3%
DC injection current(mA)	<0.5%In
Grid frequency range(Hz)	47-52 or 57-62

Efficiency
Max.efficiency	97.2%
EU efficiency	96.5%
MPPTefficiency	>99.5%

Protection
DC reverse-polarity protection	Yes
Short circuit protection	Yes
Output over current protection	Yes
Output over voltage protection	Yes
Insulation resistance monitoring	Yes
Residual current detection	Yes
Surge protection	Yes
Islanding protection	Yes
temperature protection	Yes
Integrated DC switch	Optional

General Data
Dimensins(mm)	310W373H160D
Weight(kg)	7.4
Topology	Transformerless
Self consumption (night)	<1W(Night)
Operating ambient temperature range	-25~60℃
Ingress protection	IP65
Noise emission{typical}	<20dBA
Cooling concept	Natural convection
Max.operation altitude	4000m
Designed lifetime	>20years
Grid connection standard	EN50438, AS4777.2:2015, VDE0126-1-1, IEC61727, VDE N4105, G98, G99
Relative humidity	0~100%
Safety/EMC standard	IEC62109-1/-2, NB/T 32004, EN61000-6-1, EN61000-6-3

Features
DC connection	MC-4 mateable
AC connection	IP67nrated plug
Display	LCD,2×20 Z.
Communication connections	4 pins RS485 connector
Warranty	5 years standard (extend to 20 years)

Berat:
9 kg
Dimensi:
31 × 16 × 38 cm
