Komponen ini berfungsi untuk mengubah listrik dari panel surya (DC) menjadi listrik PLN (AC). Keunggulan sistem ini memiliki sistem power manajemen yang bisa mengatur suplai energi pada siang hari.
Fitur :
Rp8,080,000 – Rp14,311,700
Compare2200 Watt, 3300 Watt, 6000 Watt
Average Star Rating: 0.0 out of 5 (0 vote)
If you finish the payment today, your order will arrive within the estimated delivery time.Only logged in customers who have purchased this product may leave a review.
Rp3,355,000
Tersedia di backorder
CompareSurge Protective Device (SPD) 3-Pole memiliki fitur indikasi visual. Surge Protective Device (SPD) cocok untuk semua sistem PV sesuai dengan IEC 60364-7-712. Dilengkapi perangkat pemutus sambungan dan hubungan pendek (shunting) gabungan dengan isolasi listrik yang aman untuk mencegah kerusakan akibat kebakaran yang diakibatan busur DC. Sekering DC terintegrasi memungkinkan penggantian modul yang aman tanpa pembentukan busur. Indikator visual hijau dan merah menunjukkan status pelindung modul (hijau = baik, merah = ganti).
SUP2H1-PV | ||||
UCPV(VDC) | 1000V | |||
Max system discharge current (8/20μs)Imax | 40KA | |||
Voltage Protection level(up) | ≤4.0KV | |||
Voltage Protection level at 5kA(up) | ≤3.6KV | |||
Integrated Fuse breaking capacity/interrupting rating | 40KA/1000vdc |
Rp685,000 Harga aslinya adalah: Rp685,000.Rp380,500Harga saat ini adalah: Rp380,500.
Stok 1
CompareThe Sunny Home Manager 2.0 is SMA’s intelligent energy manager and enables the most efficient use of solar energy in the home. It optimizes PV self-consumption and significantly reduces electricity costs. To do this, it measures the power of PV generation, purchased electricity as well as grid feed-in, and gives an overview of all relevant energy flows in the household. By means of local PV generation forecasts and the measured household consumption profile, the self-learning device prompts the user with energy-related action recommendations. Operation of the controlled appliances is coordinated in a way to optimize
the use of self-generated solar energy.
The path to intelligent energy management is quite easy. Simply install the Sunny Home Manager 2.0 at the grid connection point, connect it to the internet router using an Ethernet cable, then register the PV system in Sunny Portal free of charge and join more than 60,000 systems already installed worldwide in benefiting from greater energy efficiency
Rp15,840,000
Stok habis
CompareSolar All in One (AIO) 100 W Street Light is designed for ease of installation and easy to commission in the field by single touch of remote controller to wake up the light for operational use.The load will automatically turn On/Off by sensing the
dusk and dawn by using PV Panel voltage as sensor.
Rp7,219,000 – Rp12,708,000
CompareMID 25KTL3-X adalah inverter on-grid yang memiliki kapasitas 25KW untuk listrik 3fasa
Max. recommended PV power (for module STC) 32500W
Max. DC voltage 1100V
Start voltage 250V
Nominal voltage 580V
MPP voltage range 200V-1000V
No. of MPP trackers 2
No. of PV strings per MPP tracker 3
Max. input current per MPP tracker 25/37.5A
Max. short-circuit current per MPP tracker 32/48A
AC nominal power 25000W
Max. AC apparent power 27700VA
Nominal AC voltage 230V/400V; 340-440V
AC grid frequency 50/60 Hz (45-55Hz/55-65 Hz)
Max. output current 31.9A
Adjustable power factor 0.8leading…0.8lagging
Rp43,948,500
Tersedia di backorder
CompareSHS (solar home system) off-grid merupakan solusi untuk listrik rumah untuk daerah terpencil yang belum teraliri listrik. SHS juga dapat diterapkan untuk kebutuhan komersial seperti untuk kebutuhan lampu di kebun atau pertambangan. Untuk itu kami menawarkan SHS dengan berbagai kapasitas daya yang berbeda-beda sesuai dengan konsumen inginkan. Sistem untuk SHS kapasitas 100 Wp menggunakan tegangan 12V. Untuk SHS kapasitas 100 Wp mampu memenuhi kebutuhan listrik sebesar 350 Wh dengan sistem tegangan AC.
Kelengkapan sistem
1 Buah – Modul Fotovoltaik, 100 Wp | 1 Unit – Box Controller dan inverter 500 watt |
1 Buah – Baterai / Accu, 80 Ah | 1 Set – Rangka penyangga modul fotovoltaik |
7 M – Kabel modul uk. 2 x 2,5 mm | 1 M – Kabel instalasi uk. 2 x 2,5 mm |
1 Unit – Stop kontak | 1 Set – Aksesoris / Utility |
1 Pcs – Buku Manual + Kartu Garansi |
Rp9,400,000
Compare
Reviews
There are no reviews yet.
